TYCORUN 72v 50ah battery swappable is suitable for TYCORUN 5/12 ports swap station and can be uesd in electric motorcycle, ebike, electric scooter and other two/three – wheeled electric vehicles. There are also 60v/48v swap batteries for you to choose from.
TYCORUN ENERGY is able to provide one-stop motorcycle battery swap system solution, including two/three – wheeled swap battery, battery swap cabinet with different specifications, and battery swapping system(APP and cloud management platform).
Details of TYCORUN 72v 50ah lithium battery swappable for electric motorcycle & ev scooter
Cell type |
NMC |
Cell capacity |
50ah |
Cell voltage |
3.6V |
Charge rate |
0.5C |
Series-parallel connection |
20S1P |
4G internet |
On line |
Customized |
Yes |
Sold separately |
No |
Features of TYCORUN 72v 50ah lithium battery swappable for electric motorcycle & ev scooter
- Intelligent safety battery system design: storage safe, riding safe, charging safe.
- Cloud platform: battery data reporting to the cloud platform and battery accept instructions from the cloud system.
- Innovative pack process and manufacturing.
- Customation available.
Smart control |
Dust proof |
Anti theft |
Safe charging |
Water proof |
GPS |
Long life |
Battery health diagnosis |
Warning function |
Lightning protection |
Internet available |
IC card |
Specifications of TYCORUN 72v 50ah lithium battery swappable for electric motorcycle & ev scooter
Project |
Specifications |
Battery pack model |
EV7250N-01 |
Cell model |
27148102(3.6V 50Ah) |
Combination |
20S1P |
Typical capacity |
50Ah (standard test) |
Minimum capacity |
48Ah (standard test) |
Energy |
About 3.6Kwh |
Standard |
72V |
Shipping voltage |
>72V |
AC internal resistance |
<200mΩ |
Charge cut-off voltage |
86V |
Discharge cut-off voltage |
56V |
Standard charging method |
Charge with constant current 0.5C (25A), charge to 86V constant voltage, cut-off current 0.01C (0.5A), ambient temperature 25℃ |
Maximum charging current |
≤40A |
Standard discharge method |
Discharge with constant current of 0.5C (25A), discharge to discharge protection, ambient temperature 25℃ |
Maximum continuous discharge current |
≤50A |
Product size |
320*220*160mm |
Weight |
About 21KG |
Cycle life |
≥800 times (standard charge and discharge mode), capacity ≥80% |
Shell material |
SPCC: 1.0mm |
Range of working temperature |
Charge: 0℃–+45℃(0.2C charge) Discharge: -10~60℃(0.5C discharge) |
Storage temperature |
0℃~+45℃ |
