Silicon carbide inverter technology and advantages introduction


Tesla became the first company to use a SiC silicon carbide semiconductor field-effect transistor (MOSFET) in its own inverter design, which is reduced in size by half compared to conventional inverters.

This article introduces the silicon carbide inverter made of this transistor. Its advantages and manufacturing processes.



1. What is silicone carbide inverter

Silicon carbide inverter refers to an inverter that utilizes silicon carbide semiconductor technology in its structure. An inverter is a device that converts direct current (DC) to alternating current (AC).

It is commonly used in a variety of applications, including renewable energy systems, electric vehicles, industrial machinery, home energy storage and power electronics.

Silicon carbide is a compound semiconductor material that has higher thermal conductivity than traditional silicon-based semicon ductors, higher breakdown voltage and superior switching characteristics.

These properties make silicon carbide a good choice for power electronics such as inverters. SiC based inverters, silicon carbide inverter is known for their high power density (high power density).

What is silicone carbide inverter


This means that compared to traditional silicon-based inverters, they can deliver more power in a smaller size and lower weight, like power inverter 3000w.

This feature is particularly valuable in applications where size, weight and efficiency are critical, such as electric vehicles, where reducing weight and increasing driving range are important considerations.

2. Features of silicone carbide inverter

● Wide bandgap

SiC has wide bandgap energy, which allows it to withstand higher voltages and temperatures compared to silicon. This feature makes SiC ideal for high power and high temperature applications, as it enables higher operating frequencies and reduced power losses.

● High breakdown voltage

High breakdown voltage feature that enables SiC based devices to handle higher voltages without being broken down. This feature is advantageous in applications that require high voltage switching and power conversion, such as electric vehicles and renewable energy systems.

Features of silicone carbide inverter


● Low switching losses

SiC devices have lower switching losses compared to silicon devices. They can be turned on and off more quickly, which reduces power dissipation and improves overall energy efficiency. This advantage is particularly advantageous in high-frequency and high-power applications, such as power electronics and 2000w inverter.

3. What are the disadvantages of silicon carbide vs traditional silicon semiconductor

● High manufacturing cost

Compared with silicon devices, the manufacturing process of silicon carbide inverter is more complex and requires specialized equipment.

This results in higher manufacturing costs for silicon carbon-based inverter products. However, as the technology matures and economies of scale are achieved, costs are expected to decrease over time.

● Limited market availability

Silicon carbide inverter has not yet reached the same level of market penetration as silicon devices due to their shorter time to commercialization and lower production volumes. This can lead to limited supply and higher prices for SiC based components.

● Relatively low current handling capability

Although silicon carbide inverter has advantages in terms of voltage handling and thermal performance. However, their current handling capacity is generally lower than that of silicon devices. This may limit its use in some high-current applications.

● Complex gate drive circuitry

Due to the unique electrical characteristics of silicon carbide inverter, special grid drive circuits are required. The higher voltage and faster switching speed of SiC devices require precise gate control, which can be more complex to design and implement than silicon-based systems.

What are the disadvantages of silicon carbide vs traditional silicon semiconductor


● Substrate quality and defects

SiC substrates are often defective, or crystal imperfection, which can affect device performance and yield. Achieving high-quality and defect-free SiC substrates is challenging and increases production costs.

Ongoing research is focused on improving substrate quality and reducing defects to improve the overall performance and reliability of silicon carbide inverter.

Despite these weaknesses, SiC's advantages, such as high temperature capability, high voltage handling, and low switching losses, make it a semiconductor material with great future potential.

Ongoing research and development efforts are focused on addressing these weaknesses and further optimizing SiC technology to unlock its full potential.

4. Technical level of silicon carbide inverter

The process of designing a silicon carbide inverter involves several key steps. Generally, the following steps are involved:

● Requirements analysis

Determine the specific requirements of the PV inverter, such as input voltage range, output power, efficiency targets, switching frequency, thermal considerations, and any specific application requirements. This analysis helps determine design specifications and constraints.

● Topology slection

Common inverter topologies include single-phase or three-phase configurations, such as half-bridge, full-bridge, or multi-level topologies. Consider factors such as efficiency, power density, cost, and complexity.

Technical level of silicon carbide inverter


● Component selection

Select appropriate SiC power semiconductor devices, gate drivers, and passive components. Choose from SiC MOSFETs or Schottky diodes based on voltage and current ratings, switching characteristics, and thermal considerations.

Choose a gate driver compatible with SiC devices to ensure reliable and efficient operation.

● Circuit design

Design inverter circuit, including power stage, gate drive circuitry and protection features. Consider critical electricity, such as gate drive voltage levels, gate resistance, snubber circuits, and overcurrent/overvoltage protection mechanisms. Simulation tools are used to model and validate circuit designs.

● Control system design

This involves designing control algorithms, implementing pulse width modulation (PWM) techniques, and incorporating feedback loops for voltage and current regulation.

Consider system stability, dynamic response and protection. Simulation and modeling tools can help validate and optimize control systems.

● PCB layout and thermal management

Consider high frequency switching, reduced noise, and efficient power routing. Pay attention to thermal management techniques to ensure adequate heat dissipation, such as adding heatsinks, thermal vias and optimizing air flow.

● Prototyping and testing

Based on the design, SiC inverter prototype parts are made and perform thorough testing, including functional testing, electrical performance characterization, efficiency measurement and thermal analysis. Iteratively refine the design based on the test results and make the necessary adjustments.

● Compliance and validation

Ensure SiC inverter design meets relevant safety standards, EMC requirements and automotive industry regulations. Perform validation tests to ensure that inverters meet expected performance, efficiency and reliability goals.

● Manufacturing and production

Once the design is validated, the silicon carbide inverter is ready to be manufactured and produced. Work with manufacturers, suppliers and assembly partners to produce final products.

Compared with silicon technology, silicon carbide inverter has obvious advantages in distributed pv system and energy storage applications, which address the urgent need for energy efficiency and cost, especially when two-way power conversion is required.

5. Conclusion

Easy installation is one of the key features of high-power PV series inverters. If only two workers are needed to move and install the system, it will be very good for operation and maintenance. Therefore, size and weight are very important.

The latest generation of silicon carbide semiconductors has greatly improved the efficiency of power conversion. This not only saves energy, but also makes the silicon carbide inverter smaller and lighter, with associated capital, installation and maintenance costs lower.
